Umbilical Specs:

Application (All members are spiraled together):

• • BRC0001 – Surface dive umbilicals for communication.
  • BRP04 – Hose delivers air to measure the diver’s depth underwater.
  • BRG06 – Hose delivers air for the diver to breathe underwater.

Note: Fittings and terminations are not included

Featured:

• Tough, kink and abrasion resistant
• Buoyant in sea and fresh water
• Clean and odor free
• Flexible and non-aging

3 Part umbilical-Air, Pneumo and Comms/Strength Includes:

BRC0001 Communication Cable Specifications:

• • • Screened Pairs: 2 x 0.5 mm²
    • Polyester Strength Braid: 500 kg minimum break strength
    • Red polyurethane outer sheath: 1.7 mm nominal thickness
    • Weight in Air: 120 kg/km
    • Weight in Sea Water: 25 kg/km
    • O.D. mm: 11.0 mm
    • Standard Color: Red

BRP04 – 1/4 Inch Pneumo Hose Specifications:

• • • Hose Type: Fibrolite
    • Max Working Pressure: 400 PSI / 27.5 bar
    • Minimum Burst Pressure: 1600 PSI / 110 bar
    • Nominal Bore: 1/4 inch / 6.3 mm
    • Outside Diameter: 11.5 mm
    • Weight in Air: 82 kg/km
    • Weight in Sea Water: -25 kg/km
    • Minimum Bend Radius (Static): 75 mm
    • Minimum Bend Radius (Dynamic): 115 mm
    • Tensile Rating: 100 kg
    • Standard Color: Yellow

BRG06 – 3/8 Inch Breathing Air Hose Specifications:

• • Hose Type: Fibrolite
  • Max Working Pressure: 500 PSI / 35 bar
  • Minimum Burst Pressure: 2000 PSI / 140 bar
  • Nominal Bore: 3/8 inch / 9.5 mm
  • Outside Diameter: 17.5 mm
  • Weight in Air: 193 kg/km
  • Weight in Sea Water: -53 kg/km
  • Minimum Bend Radius (Static): 105 mm
  • Minimum Bend Radius (Dynamic): 1160 mm
  • Tensile Rating: 100 kg
  • Standard Color: Blue

Fittings

Note:

• • Crimp down diameters (CDD) are for Bruce Systems phosphor bronze hose end fittings for the Novadive ranges of diving hoses

3/8 Inch ID #6 JIC Hose Fitting Specifications:

• Hose Details:
  • • Bore (ID): 3/8 inch
    • Hose Type: Novadive
    • Hose Fitting: #6 JIC
    • Part Number: BRG06 – Novadive
    • D.: BRU06 – 18.50 mm
    • Max Working Pressure: BRU06 – 500 PSI (35 bar)

Ferrule O.D.:

• • Body Material: Swageable Phosphor-Bronze
  • Pre Swage: 25.4 mm
  • Post Swage: BRU06 – 23.0 CDD ± 0.20 mm

Note:

• • Crimp down diameters (CDD) are for Bruce Systems phosphor bronze hose end fittings for the Novadive ranges of diving hoses.

1/4 Inch ID #4 JIC Hose Fitting Specifications:

• Hose Details:
  • • Body Material: Swagable Phosphor – Bronze
    • Bore: 1/4 inch
    • Hose Type: Novadive
    • Hose Fitting: #4 JIC
    • Part Number: BRP04
    • O.D.: 11.50 mm
    • Max Working Pressure: 400 PSI (27 bar)

Ferrule O.D.:

• • Pre Crimp: 19.00 mm
  • Post Crimp: 16.00 CDD ± 0.20 mm

Note: Crimp down diameters (CDD) are for Bruce Systems phosphor bronze hose end fittings for the Novadive ranges of diving hoses.
